Product Description
Feilong 68 model high speed rapier loom adopts mature rapier weaving technology and absorbs the most advantageous international intermediate beating-up mechanism of loom and unique sword belt driving technology for perfect combination, improving weaving output of the latest loom. Its extremely solid fuselage structure ensures high stability and low solid fuselage construction which enables it to easily weave various heavy or other kinds of necessary fabrics.
Performance
· High speed
· Excellent fabric quality
· High efficiency
Investment & Use cost
· Low investment
· Fast return
· Long service life
· Low energy consumption
· Less maintenance
· Low consumption of spare parts
Simplicity
· Easy operation
· Quick replacement variety
· Wide variety adaptability
Product Parameters
Reed Width | 190, 210, 220, 230, 260cm (narrow-weaving machine) 280, 340, 360 cm (wide-weaving machine),380cm,410cm, 520cm, 580cm, 600cm |
Weaving shrinkage | 70cm (narrow-weaving machine), 90cm (wide-weaving machine) |
Loom drive | Directly driven by switched reluctance main motor |
Speed | Designed maximum speed of 750 rpm, Economical speed of 550-600 rpm |
Filling insertion rate | Up to 1425 m / min |
Weft color selection | Programming of 1-8 color or different specifications. |
Weft insertion | Unique weft insertion mechanism with the space connecting bar (patent).
16mm narrow sword belt, single guide flight system.
27mm wide sword belt, unguided flight system (optional). |
Let-off | Servo motor control 850Kg weighing tension sensor. Warp beam removing device Double back rest system |
Shedding | STAUBLI 2658B electronic rotating dobby Up to 20 head frame tappet motions (optional), jacquard head (optional). |
There are nearly 20,000 units Feilong 68 model high speed rapier looms in operation on the market, mainly used in clothing fabrics, industrial fabrics and other fields, and are the main models for export.
Main techanic Datas:
1. The high-force torque motor is used as the main drive and powerful clutch to realize starting and braking, which maximizes the quality of the cloth surface;
2. Electronic dobby opening: up to 20 heald frames;
3. Space four-link mechanism weft insertion: separate reed seat, weft insertion on both sides, middle handover; There are two ways of guide hook weft insertion and free flight weft insertion;
4. Electronic let-off and electronic take-up realize constant tension weaving and variable weft dense weaving.
